DETAILED INTRODUCTION
OVERVIEW
FRAME
HIGH PIVOT FRAME SYSTEM
The high-pivot frame system creates a more rearward axle path as the suspension compresses, resulting in a noticeably faster, more aggressive, and confident feel on both descents and climbs. An idler is used to reduce chain growth and pedal kickback, while also enhancing the bike’s anti-squat characteristics, leading to increased stability and control.
148MM BOOST REAR DROPOUT
A wider chainstay requires a wider hub and axle, which increases lateral stiffness and allows for stronger, stiffer wheels. It also provides additional tire clearance, giving riders the option to run wider tires and offering more flexibility in tire choice.
INTERNAL CABLE ROUTING
The internal cable routing system delivers a sleek, streamlined appearance. Each cable hole is fitted with gaskets to eliminate rattling and cable rub.
ISCG-05 SYSTEM
It features an ISCG-05 tab to mount the chain guides to frames, which reduces the dropping chain and stables the works.
HIGH PIVOT CHAIN GUIDE
DA BOMB HP1 Chain Guide is designed for high-pivot frame systems. The 14T oversized pulley inside the large-diameter roller features tight clearances, enhancing guiding efficiency and reducing noise by minimizing the chain's articulation angle and the risk of chain seizing.
DOUBLE-LAYER SEAT CLAMP
Designed for Super-Enduro riding, this clamp ensures your seatpost stays securely in place, no matter how extreme or brutal the conditions. The upper water-resistant edge helps prevent mud and dust from entering the seat tube.
CHAIN PROTECTION
The chainstay is protected with durable rubber guards that shield the paint finish from chain strikes without causing scratches. It’s a simple yet highly effective solution!
BOTTLE CAGE MOUNT
It can accommodate the DA BOMB CARTRIDGE CASE (compound water bottle cage), which features built-in repair tools and mini storage.
COMPATIBILITY
SRAM and SHIMANO.The difference between the two editions lies in the idler adapter: the SRAM edition includes a 55mm adapter, while the SHIMANO edition includes a 52mm adapter.Please read the instruction manual carefully before assembly to avoid purchasing incompatible components. For the SRAM edition, ensure that your crankset, derailleur, cassette, and chain are compatible with the SRAM Transmission T-Type series.
SPECIFICATIONS
• Material: Aluminum
• Size: S / M / L
• Tapered Head Tube: ZS44/ZS56
• Travel: 170mm
• Shock Compatibility: L205*TR65*M8 (FW54*RW22), Trunnion-Type
• Seat Post Diameter: 31.6mm
• BB Width: 73mm w/ ISCG05 mount
• Rear Dropout: 148mm * 12mm * P1.0
• Included: Rear Axle / Seat Clamp / UDH Hanger /
• Weight (without shock): 4100g (S) / 4200g (M)
• Maximum Tire Size: 29” * 2.6”
• Color Options: Gloss Pearl White
